Azden SGM-3500

Azden SGM-3500 flagship broadcast shotgun microphone w/ improved frequency response, increased sensitivity, all brass body, super-cardioid pattern, foam windscreen & hardshell case

The Azden 3500 range of rifle-style, directional microphones will meet the needs of even the most demanding film and television sound engineers. The SGM-3500/3500L microphones feature a condenser insert with low self-noise (13dBA), high sensitivity, and slight frequency emphasis in the 5 - 10 kHz range for good speech intelligibility, as well as a solid brass body for RF interference suppression and field durability, XLR connector with gold-plated pins, and a 10-year warranty

• Microphone cartridge: condenser
• Frequency response: 40 Hz - 20 kHz
• Sensitivity: 3500: -31 dB, 3500L: -28 dB @ 1 kHz (0 dB = 1 V/Pa)
• Noise: 13 dB (A)
• Dynamic Range: 118 dB
• Output impedance: 120 Ohm (@ 1 kHz)
• Max. 130 dB SPL (1 kHz at 1% THD)
• Signal to Noise: 82 dB (1 kHz @ 1 Pa)
• Power supply: 48 V phantom (±4 V )
• Connector: XLR3
• Dimensions: 3500: 180 x 19 mm, 3500L: 247 x 19 mm
• Weight: 3500: 140 g, 3500L: 170 g
• Accessories included: hard box, holder, foam wind protector
