BON FM-055F

Featuring 5” 1920x1080 LED back lit LCD panel, the lightweight (365 g) FM-055F is an excellent 5” on-camera monitor for DSLR and ENG cameras, providing HDMI to SDI conversion, DSLR scale, focus peaking, selectable loop-through or conversion out, markers, de-embedded 8~16ch audio level meter, horizontal/vertical screen flipping, and range error check.

Universal Solution
The FM-055F has four mount holes on top, bottom, left and right side to attach it on any camera or arm. All buttons and a wheel are conveniently located on the top of the monitor, while SDI and HDMI connectors are on the bottom. Offering an outstanding picture quality, this lightweight and ergonomic camera monitor is convenient and easy to use in any shooting environment. The monitor requires external DC power 6.5-18V (up to 12V adapters and 18V batteries), DV battery mount (Sony NP-F/BP-U, Canon LP-E6, Panasonic CGA) is an optional accessory, as is the sun hood, and screen protector.



SDI/HDMI Conversion
In addition to excellent Full HD, LED-backlit display (450 cd/m?, 1000:1) with excellent image quality, the FM-055F also offers a wealth of functions, including SDI/HDMI cross-conversion! Not only you can do SDI Loop out and HDMI Loop Out, you can also convert SDI to HDMI Out and HDMI to SDI OUT. It is a true 1:1 conversion. the output is always the same resolution as the input. Another useful feature is a horizontal/vertical level meter showing the alignment of the monitor, and an auto-flip function.



Features:
3G/HD/SD-SDI and HDMI (with HDCP 1.1) inputs
HDMI-to-SDI & SDI-to-HDMI conversion
Headphone and speaker (0,5W, mono) outputs
Power consumption 10W
Horizontal/vertical level meters
Auto color temperature adjustment
Auto flip
Focus assist
False color
Various markers (EBU, 4:3, 16:9, 1.85:1, 2.35:1, etc.)
Zero/under/over scan
Blue/mono
H/V delay
Pixel-to-pixel view
USB memory update
DV-battery level indicator
Tally automatically turns on when recording (Arri, Red)
Color calibration for optimal luminance, gamma, color temperature
Waveform / vector scope
Time code
8~16ch audio level meter
Exposure range check
R/G/B/W internal patterns
