Datavideo HDR-70

The Datavideo HDR-55 is a hard drive based video recorder & player, with a removable hard drive enclosure.

More information

2 659 € with VAT 2 197.52 € without VAT
-+
Availability
14-30 days
Product description

Product description

The Datavideo HDR-55 is a hard drive based video recorder & player, with a removable hard drive enclosure.

The Datavideo HDR-70 is a rackmountable hard drive based video recorder & player, with a removable hard drive enclosure.

HDR-70 HD/SD Digital Video Recorder
Video Standard

HD & SD

Video Format

1080p 23.97/24Hz
1080i 50/59.94/60Hz
720p 50/59.94/60Hz
576i 50Hz, 480i 59.94Hz

Supported Video Input Signal

1x SDI

Monitoring / Playback Output

1x SDI (Input Loop Thru)
1x HDMI, 1x SDI (Out)

Analog Audio Input / Output

2x Balanced XLR (Stereo pair)

Embedded Audio

Both In & Out (8-CH on SDI/HDMI)

Storage Medium

2.5" Hard Drive / SSD*, Max capacity 1TB

Estimated Record Time (min per 10GB)

SD: 19 (50Mbps) ~ 70 (8Mbps)
HD: 8 (125Mbps) ~ 62 (10Mbps)

Recording Media

Removable Hard Drive / SSD,
transfer data via USB2.0

Storage File System

NTFS (read only)

Recorded File Format

MXF OP1A, MOV

Video Recording Bit Rate / Color Sampling

MPEG2 Long GOP HD:
1. 10Mbps 4:2:0 1440x1080/1280x720,
2. 25Mbps 4:2:0 1440x1080/1280x720,
3. 35Mbps 4:2:2 1920x1080/1280x720,
4. 50Mbps 4:2:2 1920x1080/1280x720,
5. 65Mbps 4:2:2 1920x1080/1280x720,
6. 120Mbps 4:2:2 1920x1080/1280x720,
MPEG2 Long GOP SD
1. 8Mbps 4:2:0 720x480/720x576
2. 15Mbps 4:2:2 720x480/720x576
3. 30Mbps 4:2:2 720x480/720x576
4. 50Mbps 4:2:2 720x480/720x576
MPEG2 I-Frame Only HD
1. 80Mbps 4:2:2 1920x1080/128

Audio Recording Format

Uncompressed PCM
Sampling rate 48KHz 24bit

Time Code In / Out

Yes

External Sync / Genlock

Black Burst & Tri-level with loop thru

Power Failure Protection

Content saved up to last 3 seconds or less before power failure

Chassis

1RU 19” rack-mountable

Dimension (LxWxH)

288 x 481 x 49 mm

Weight

3.1 kg

Operating Temp. Range

0~40 °C

Power

DC 12V, 2A

What's in the Box

1 x HDR-70 product
1 x AD Switch DC 12V
1 x USB Cable (Y type)
2 x 2.5" Removable HDD Enclosure (HDD Not Included)
10 x M3 X 4 m/m Screws
2 x 2.0 X 6 m/m Screws
2 x HD Label
4 x Label
2 x L type stand
1 x Thank You Card

Parameters

Parameters

Manufacturer: Datavideo
Category: Studio recorders
