Datavideo PTC-140 NDIW

Add an HD camera with NDI streaming capability to your broadcast, house of worship, corporate, or education environment with this dark blue PTC-140NDI SDI/HDMI/NDI PTZ Camera with 20x Optical Zoom from Datavideo. The versatile PTZ supports frame rates and resolutions up to 1080p60 and…

More information

1 269 € with VAT 1 048.76 € without VAT
-+
Availability
14-30 days

Show all accessories

Product description ARTICLES

Product description

Add an HD camera with NDI streaming capability to your broadcast, house of worship, corporate, or education environment with this dark blue PTC-140NDI SDI/HDMI/NDI PTZ Camera with 20x Optical Zoom from Datavideo. The versatile PTZ supports frame rates and resolutions up to 1080p60 and features a 1/2.8" CMOS sensor with 2.07 MP resolution. The built-in zoom lens features an optical zoom range of 20x, and you can zoom in even further with the 10x digital zoom. It supports HDMI, SDI, and NDI|HX video output compatible with any standard NDI network or any video streaming platform such as YouTube, Skype, WebEx, Zoom, and many others.

With 255 programmable preset positions, you can set the camera to rapidly move to between positions using DVIP, RS-232 serial, or IR control, and it features a built-in tally light. The camera compresses using either or both the H.264 and H.265, as its onboard encoder is capable of encoding two streams at the same time. You can stream live using RTSP or RTMP protocols as well as stream video and control when on an NDI network using high-quality, low-latency HDI|HX technology. The camera supports external audio via a 3.5mm stereo line-level input as well as embedded audio using AAC, MP3, and G.711a compression formats.

The camera can be powered using the included power adapter or by using PoE (Power-over-Ethernet) to cut down on cabling within your environment.

Suitable for broadcast, worship, video conferencing, corporate, and education environments
Video streaming application support for services such as Skype, GoToMeeting, WebEx, Zoom, and YouTube
Output resolution up to 1920 x 1080p60 with a 2.07MP 1/2.8" CMOS sensor
20x optical zoom, 10x digital zoom; M52 lens filter thread with UV filter and can be removed for optional filters
Single-cable concept helps you to transfer video, audio, power, tally, and control over only one Ethernet cable via NDI|HX and PoE (Power-over-Ethernet)
Advanced 2D/3D noise reduction technology is used to further reduce the noise, ensuring image sharpness
Analog 3.5mm audio input interface; supports AAC, MP3, and PCM audio compression output
Supports compression of resolutions up to 1920 x 1080p60 and 2-channel 1920 x 1080p30
Multiple Network Protocols: RTSP, RTMP protocols and support, easy to link to a streaming media server
RS-232, RS-422, and RS-485 ports to use DVIP and VISCA commands to integrate with larger control systems
Tally lights show the preview and program status
Compatible with optional RMC-180, RMC-300C, and RMC-300A camera control units

ARTICLES

Parameters

Parameters

Manufacturer: Datavideo
Category: PTZ

Main parameters

ResolutionFull HD
Type of bayonetintegrated lens
OutputHDMI
OutputNDI
Output3G SDI

Other parameters

VersionPTZ
FPSHD 60fps
Lens lens aperture1.6f
Min. focal length5.2mm
Max. focal length98mm
Other featuresPTZ
Other featuresStreaming
Other featuresPoE
Other featuresNDI / NDI HX
Control protocolNDI
Control protocolRS-422
