DECIMATOR DESIGN DMON-4S

669 € with VAT 552.89 € without VAT
-+
Availability
on request
Product description

Product description

4 x (3G/HD/SD)-SDI to HDMI Converters with 1 to 4 MultiViewer, Custom Layouts and 8 Channel Audio Meters
  • Multi-View mode now includes 8 Channel Audio Metering overlay per window with individual enables, custom positioning and size
  •
    Support for both 3G level A and B on the inputs.
  •
    Horizontal and/or Vertical image flipping per window
  •
    Includes 4 independent mini HDMI outputs that can each output any of the four (3G/HD/SD)-SDI inputs or a Multi-View of all them. For example you could use the unit to have:
  •
    4 independent SDI to HDMI converters
  •
    3 independent SDI to HDMI converters with a quad-split output
  •
    2 independent SDI to 2 x HDMI converters with loop through
  •
    A single SDI or Multi-View to 4 x HDMI outputs
  •
    Inputs 2 and 4 can be individually changed to output active loop copies of inputs 1 and 2 respectively.
  •
    Multi-View mode offers:
  •
    Custom Layouts with various standard layouts
  •
    Load and restore Custom Layouts
  •
    Fast switching between inputs using Full-Screen scaling
  •
    Selection of audio from any input
  •
    16 Character UMD overlay per window with individual enables, custom positioning and size
  •
    Low latency buffering for each input allowing non-synchronous inputs
  •
    Each window is independent of the others, allowing any 3G/HD/SD format of any frame rate to be displayed simultaneously
  •
    Variable aspect ratios per window
  •
    The DMON-4S is a truly portable converter, that incorporates our new
    easy to use LCD and button control system.
  •
    This unit also includes:
  •
    USB port for control and firmware updates
  •
    Heavy duty metal box
  •
    Metal Thread Locking DC Power Socket
  •
    Power Supply, HDMI Cable and USB Cable
Parameters

Parameters

Manufacturer: Decimator Design
Category: Multiviewer

Main parameters

Resolution multiviewHD
Resolution multiviewSD
Number of inputs4
