Model Name |
FUJIFILM X-T5 |
Lens Mount |
FUJIFILM X bayonet |
Image sensor |
23.5 x 15.7 mm (APS-C) X-Trans CMOS 5 HR with primary colour filter |
Effective pixel count |
40.2 million pixels |
Sensor cleaning system |
Ultra Sonic Vibration |
Image processing engine |
X-Processor 5 |
Storage Media |
SD card (-2 GB) / SDHC card (-32 GB) / SDXC card (-2 TB) / UHS-I / UHS-II / Video Speed Class V90 *For more detailed information, please refer to the Compatibility page. |
Still image file format |
DCF |
In accordance with the camera file system design rules (DCF2.0) |
|
JPEG |
Exif Ver.2.32*1 |
|
HEIF |
4:2:2 10bit |
|
RAW |
14bit RAW (original RAF format) |
|
TIFF |
8bit / 16bit RGB (in-camera raw format conversion only) |
Number of recorded pixels |
[L] |
〈4:3〉 6864 x 5152 〈3:2〉 7728 x 5152 〈16:9〉 7728 x 4344 〈1:1〉 5152 〈5:4〉 6432x5152 |
|
[M] |
〈4:3〉 4864 x 3648 〈3:2〉 5472 x 3648 〈16:9〉 5472 x 3080 〈1:1〉 3648 x 3648 〈5:4〉 4560x3648 |
|
[S] |
〈4:3〉 3456 x 2592 〈3:2〉 3888 x 2592 〈16:9〉 3888 x 2184 〈1:1〉 2592 x 2592 〈5:4〉 3264x2592 |
Panorama |
[L] |
〈Vertical〉 9600 x 2160 〈Horizontal〉 9600 x 1440 |
|
[M] |
〈Vertical〉 6400 x 2160 〈Horizontal〉 6400 x 1440 |
Digital teleconverter |
2.0x / 1.4x / OFF |
Sensitivity |
Static image |
Standard output: AUTO1 / AUTO2 / AUTO3 /ISO125 - 12800 (1/3 step) Extended Output: ISO64 / ISO80 / ISO100 / ISO25600 / ISO51200 |
|
Film |
Standard Output: AUTO / ISO125 - 12800 (1/3 step) Extended Output: ISO25600 |
Exposure control |
TTL 256-zone metering / Multi / Spot / Average / Center Weighted |
Exposure Mode |
P (Program AE) / A (Aperture priority AE) / S (Shutter speed priority AE) / M (Manual exposure) |
Exposure Compensation |
Still |
-5.0EV - +5.0EV in 1/3EV steps |
|
Filming |
-2.0EV - +2.0EV in 1/3EV steps |
Image Stabilizer |
Mechanism |
Image sensor shift mechanism with five-axis compensation |
|
Compensation effect |
7.0 degrees *based on CIPA standard *Only jitter in the direction and against the direction of rotation *With XF35mmF1.4 R lens attached |
|
Digital image stabilization |
Yes (video mode only) |
|
IS MODE BOOST |
Yes (movie mode only) |
Shutter type |
Focal plane shutter |
Shutter speed |
Mechanical shutter |
P mode: 30sec. 1/8000sec. A mode: 30sec. to 1/8000sec. S/M mode: 15min. to 1/8000sec. Bulb mode: up to 60min. |
|
Electronic shutter |
P mode: 30sec. up to 1/180000sec. A mode: 30sec. up to 1/180000sec. S/M mode: 15min. to 1/180000sec. Bulb: 1sec. Fixed *Shutter speed ranges for continuous shooting mode may differ from those shown here. |
|
Electronic front aperture |
P mode: 30sec. to 1/8000sec. A mode: 30sec. to 1/8000sec. S/M mode: 15min. to 1/8000sec. Bulb mode: up to 60min. |
|
Mechanical + electronic shutter |
P mode: 30sec. up to 1/180000sec. A mode: 30sec. up to 1/180000sec. S/M mode: 15min. to 1/180000sec. Bulb: up to 60min. *Mechanical shutter operates up to 1/8000sec. *Shutter speed ranges for continuous shooting mode may differ from those shown here. |
|
E-front + mechanical shutter |
P mode: 30 sec. to 1/8000 sec. A mode: 30 sec. to 1/8000 sec. S/M mode: 15min. to 1/8000sec. Bulb mode: up to 60min. *Electronic front aperture works up to 1/2000sec. |
|
Electronic front + mechanical + electronic shutter |
P mode: 30sec. up to 1/180000sec. A mode: 30sec. up to 1/180000sec. S/M mode: 15min. to 1/180000sec. Bulb: up to 60min. *Electronic front aperture works up to 1/2000 sec, mechanical shutter works up to 1/8000 sec. *Electronic shutter may not be suitable for fast moving subjects or handheld photography. Flash cannot be used. *Shutter speed ranges for continuous shooting mode may differ from those shown here. |
|
Video |
6.2K: 1/8000 s to 1/24 s. DCI4K/4K: 1/8000 s to 1/4 s. FHD: 1/8000 s to 1/4 s. *For some settings, a shutter speed longer than the frame rate cannot be selected. |
|
Synchronized shutter speed for flash |
Mechanical shutter: 1/250 sec. or slower |
Continuous shooting |
CH Electronic Shutter Approximately 20 fps (1.29x crop) (JPEG 168 frames, Compressed RAW 72 frames, Lossless Compressed RAW 41 frames, Uncompressed RAW 23 frames, Compressed RAW + JPEG 37 frames, Lossless Compressed RAW + JPEG 31 frames, Uncompressed RAW + JPEG 23 frames) CH Electronic Shutter Approx. 13 fps (1.29x crop) (JPEG 1000+ frames, Compressed RAW 104 frames, Lossless Compressed RAW 53 frames, Uncompressed RAW 23 frames, Compressed RAW + JPEG 56 frames, Lossless Compressed RAW + JPEG 44 frames, Uncompressed RAW + JPEG 23 frames) CH Electronic Shutter Approx. 10 fps (1.29x crop) (JPEG 1000+ frames, compressed RAW 1000+ frames, lossless compressed RAW 70 frames, uncompressed RAW 25 frames, compressed RAW + JPEG 72 frames, lossless compressed RAW + JPEG 53 frames, uncompressed RAW + JPEG 23 frames) CH Electronic shutter Approximately 13 fps (JPEG 163 fps, compressed RAW 56 fps, lossless compressed RAW 29 fps, uncompressed RAW 22 fps, compressed RAW + JPEG 32 fps, lossless compressed RAW + JPEG 26 fps, uncompressed RAW + JPEG 20 fps) CH Electronic shutter Approx. 8.9 fps (JPEG 1000+ frames, compressed RAW 94 frames, lossless compressed RAW 40 frames, uncompressed RAW 23 frames, compressed RAW+JPEG 45 frames, lossless compressed RAW+JPEG 30 frames, uncompressed RAW+JPEG 22 frames) CH Mechanical Shutter Approximately 15 fps (JPEG 119 fps, compressed RAW 39 fps, lossless compressed RAW 22 fps, uncompressed RAW 19 fps, compressed RAW+JPEG 27 fps, lossless compressed RAW+JPEG 21 fps, uncompressed RAW+JPEG 19 fps) CH Mechanical Shutter Approx. 10 fps (JPEG 1000+ frames, compressed RAW 56 frames, lossless compressed RAW 29 frames, uncompressed RAW 19 frames, compressed RAW+JPEG 34 frames, lossless compressed RAW+JPEG 25 frames, uncompressed RAW+JPEG 19 frames) CL Mechanical Shutter Approximately 7.0 fps (JPEG 1000+ frames, compressed RAW 1000+ frames, lossless compressed RAW 33 frames, uncompressed RAW 20 frames, compressed RAW+JPEG 45 frames, lossless compressed RAW+JPEG 22 frames, uncompressed RAW+JPEG 20 frames) Preset Electronic Shutter Approximately 20 frames per second (1.29x crop) (Half-press 20 frames, Full-press 140 frames) Electronic shutter speed Approximately 13 fps (1.29x crop) (Half-press 13 fps, Full-press 300 fps) Pre-shooting Electronic shutter Approximately 10 fps (1.29x crop) (10 frames at half-press, 370 frames at full-press) Preframe Electronic shutter Approximately 13 fps (13 frames at half-press, 70 frames at full-press) *The number of recorded frames depends on the recording medium *Continuous shooting speed depends on the shooting environment and the number of frames taken |
Drive mode |
Bracketing AE |
2 frames / 3 frames / 5 frames / 7 frames / 9 frames *1/3EV increments, up to ±3EV increments |
|
Bracketing with film simulation |
Choice of any 3 types of film simulation |
|
Dynamic range bracketing |
100% / 200% / 400% |
|
ISO sensitivity bracketing |
±1/3EV / ±2/3EV / ±1EV |
|
White balance bracketing |
±1 / ±2 / ±3 |
|
Focus Bracketing |
AUTO / MANUAL |
|
Multiple Exposure |
Yes (max. 9 shots) / additive / average / light / dark |
|
HDR mode |
AUTO / 200% / 400% / 800% / 800% + |
|
Advanced filter |
Toy camera / Miniature / Pop color / High key / Low key / Dynamic tone / Soft focus / Partial color (red / orange / yellow / green / blue / purple) |
|
Pixel Shift Multi Shot |
Yes |
Focus |
Mode |
Single Auto Focus / Continuous Auto Focus / MF |
|
Type |
Intelligent Hybrid AF (TTL Contrast AF / TTL Phase Detection AF) |
|
Low light performance |
Contrast: -4.0EV XF50mmF1.0 connected Phase Detection: -7.0EV XF50mmF1.0 connected |
|
AF frame selection |
Single-point AF: 13x9 / 25x17 (AF frame resizable) Zone AF: 3x3 / 5x5 / 7x7 of 117 areas on 13×9 grid Wide Angle/Tracking AF: Yes (AF-S: Wide Angle / AF-C: Tracking) All: Yes |
|
Face/Eye Detection |
Yes |
|
Subject detection |
Yes (Animal/Bird/Automobile/Motorcycle&Bike/Aircraft/Train) |
Flash |
EF-X8 |
Aiming number: approx. 11 (ISO200・m) / approx. 8 (ISO100・m) Synchronization. Mode: 1st aperture / 2nd aperture Flash mode: TTL (TTL AUTO / STANDARD / SLOW SYNCHRONIZATION ) / MANUAL / COMMANDER / OFF |
|
Flash with socket |
Sync. Mode: 1st Aperture / 2nd Aperture / AUTO FP (HSS) Flash mode: TTL (TTL AUTO / STANDARD / SLOW SYNC. ) / MANUAL / MULTI *When EF-X500 / OFF setting |
|
Synchronized terminal |
Sync. Mode: 1st Aperture / 2nd Aperture Flash mode: MANUAL |
Hot shoe |
Yes (compatible with dedicated TTL flash) |
Viewfinder |
EVF: 0.5" OLED colour viewfinder, approx. 3.69 million dots Imaging area coverage vs. sensing area: Approx. 100% Approximately 24 mm (from the rear end of the camera eyepiece) Diopter adjustment: -5 - +3m-1 Magnification: 0.80x with 50mm lens (35mm equivalent) at infinity and diopter set at -1.0m-1 Angle of view: approx. 39° (horizontal angle of view: approx. 32° ) Built-in eye sensor |
LCD monitor |
3.0-inch (three-directional) color LCD touch screen monitor Aspect ratio: 3:2 Number of dots: approximately 1.84 million dots |
Touch screen mode |
Photography mode |
Shooting, autofocus, focus area, off, double tap setting (on/off), touch function setting (on/off), touch zoom (on/off), touch screen area setting EVF |
|
Playback mode |
Swipe, Zoom in/out, Double tap, Drag |
Video recording |
File format |
MOV: HEVC/H.265, Linear PCM (24bit/48KHz stereo audio sampling) MPEG-4 AVC/H.264, Linear PCM (24bit/48KHz stereo audio sampling) MP4: MPEG-4 AVC/H.264, AAC |
|
Movie compression |
All internal/long GOP |
|
File size Frame rate Bitrate |
[6.2K(16:9)] 6240 x 3510 29.97p/25p/24p/23.98p 360Mbps/200Mbps/100Mbps/50Mbps [DCI4K HQ(17:9)] 4096 x 2160 29.97p/25p/24p/23.98p 360Mbps/200Mbps/100Mbps/50Mbps [4K HQ(16:9)] 3840 x 2160 29.97p/25p/24p/23.98p 360Mbps/200Mbps/100Mbps/50Mbps [DCI4K(17:9)] 4096 x 2160 59.94p/50p/29.97p/25p/24p/23.98p 360Mbps/200Mbps/100Mbps/50Mbps [4K(16:9)] 3840 x 2160 59.94p/50p/29.97p/25p/24p/23.98p 360Mbps/200Mbps/100Mbps/50Mbps [Full HD(17:9)] 2048 x 1080 59.94p/50p/29.97p/25p/24p/23.98p 360Mbps/200Mbps/100Mbps/50Mbps [Full HD(16:9)] 1920 x 1080 59.94p/50p/29.97p/25p/24p/23.98p 360Mbps/200Mbps/100Mbps/50Mbps [Full HD(17:9) High Speed Recording] 2048 x 1080 240p/200p/120p/100p 360Mbps(recording)/200Mbps(recording) [Full HD(16:9) High Speed Recording] 1920 x 1080 240p/200p/120p/100p 360Mbps(record)/200Mbps(record) *Use an SD memory card with a speed class of UHS 3 or higher to record movies. *For 360 Mbps movie recording, use an SD memory card with a video speed class of 60 or higher. *The selected bitrate will change depending on the setting. *Recording time may be reduced depending on temperature and/or shooting conditions |
Film simulation mode |
19 modes (PROVIA/Standard, Velvia/Vivid, ASTIA/Soft, Classic Chrome, PRO Neg.Hi, PRO Neg.Std, Classic Neg., Nostalgic Neg., ETERNA/Cinema, ETERNA BLEACH BYPASS, ACROS, ACROS + Ye Filter, ACROS + R Filter, ACROS + G Filter, Black & White, Black & White + Ye Filter, Black & White + R Filter, Black & White + G Filter, Sepia) |
Monochrome |
Yes |
Grain effect |
Roughness |
STRONG, WEAK, OFF |
|
Size |
LARGE, SMALL |
Color Chrome Effect |
STRONG, WEAK, OFF |
Colour chrome Blue |
STRONG, WEAK, OFF |
Smooth skin effect |
STRONG, WEAK, OFF |
Dynamic range adjustment |
Still |
AUTO / 100% / 200% / 400% ISO limitation: DR100%: No limitation、DR200%: ISO250 or more、DR400%: ISO500 or more |
|
Film |
100% / 200% / 400% ISO limitation: DR100%: No limitation、DR200%: ISO250 or more、DR400%: ISO500 or more |
White balance |
Automatically |
White Priority / Auto / Ambient Priority |
|
Custom |
Custom1 - 3 |
|
Color Temperature Selection |
2500K - 10000K |
|
Preset |
Daylight / Shade / Fluorescent-1 / Fluorescent-2 / Fluorescent-3 / Incandescent / Underwater light |
Brightness setting |
±5 steps |
Self-timer |
Still |
10sec. / 2sec. |
|
Video |
10sec. / 5sec. / 3sec. |
Interval shooting with timer |
Yes (Settings : Interval, Frame rate, Start time, Interval exposure smoothing, Interval priority mode) |
Wireless transmitter |
Standard |
IEEE802.11a/b/g/n/ac (standard wireless protocol) |
|
Encryption |
WPA/WPA2 mixed mode, WPA3 |
|
Access mode |
Infrastructure |
Bluetooth® |
Standardd |
Bluetooth Ver. 4.2 (Bluetooth low energy) |
|
Operating frequency (medium frequency) |
2402 - 2480 MHz |
Terminal |
Digital interface |
USB Type-C (USB3.2 Gen2x1) |
|
HDMI output |
HDMI Micro connector (type D) |
|
Other |
ø3.5 mm, stereo mini connector (microphone) ø2.5 mm, remote control connector Hot shoe Synchronized terminal |
Power supply |
Lithium-ion battery NP-W235 (included) |
|
Battery life for still images*2 |
Power saving mode: Approximately 740 shots Normal mode: Approximately 580 shots *At XF35mmF1.4 R setting |
|
Actual battery life during movie shooting*2 |
6.2K: Approximately 90 minutes (29.97p) 4K: Approximately 80 minutes (59.94p) Full HD: (59.94p), approx. 100 min. (120P) *Face detection is set to OFF |
|
Continuous battery life during video recording*2 |
6.2K: Approx. 130 min. (29.97p) 4K: Approximately 130 min (59.94p) Full HD: (59.94p) *Face detection is set to OFF |
Dimensions |
Width: 129.5 mm Height: 91 mm Depth: 63.8 mm (Minimum depth: 37.9 mm) |
Weight |
including battery and memory card: Approximately 557 g (with battery and memory) without battery and memory card: Approximately 476 g |
Operating environment |
Operating temperature |
-10℃ - +40℃ |
|
Operating humidity |
10% - 80% (non-condensing) |
Start-up time |
Approximately 0.49 s |
Supplied accessories |
Li-ion battery NP-W235 AC-5VJ power adapter Power outlet adapter USB cable Headphone adapter Shoulder strap Body cover Hot shoe cover Sync terminal cover |
