Metabones Smart Adapter EF-FZ Mount CINE

Addressing the demands of broadcast professionals and cinematographers to tap into the vast selection of EF and EF-S mount lenses, Metabones Smart Adapter EF-FZ Mount enables to attach Canon lenses on Sony CineAlta cameras such as F5 and F55. Designed for dependable operation in the field, this new Smart Adapter features an extra large, geared iris ring and an easy-to-turn breech-lock to solidly secure the EF/EF-S mount lens.

Addressing the demands of broadcast professionals and cinematographers to tap into the vast selection of EF and EF-S mount lenses, Metabones Smart Adapter EF-FZ Mount enables to attach Canon lenses on Sony CineAlta cameras such as F5 and F55. Designed for dependable operation in the field, this new Smart Adapter features an extra large, geared iris ring and an easy-to-turn breech-lock to solidly secure the EF/EF-S mount lens. Electronic integration includes viewfinder display of aperture, zoom and distance, auto exposure, an assignable function button and image stabilization (IS) lens support. No additional power source is required. Adapter firmware is user-upgradable through the micro USB port on the Smart Adapter.

High Precision
The Smart Adapter series of products add industry-leading electronic interfacing technology with true electronic control of the lens' aperture directly from the camera body. Both camera-side and lens-side of the adapter are made of brass, precision-machined and plated with chromium, while the rest of the product is coated in satin surface finish. Precise fit and solid connection ensureslens has no play, gap or wiggling when mounted on adapter and no adjustments are required to fit your lens. The Smart Adapter is designed to reach infinity focus while maintaining the correct registration distance required to maintain optical quality of CRC lenses or lenses with floating elements.



Electronic Integration
True electronic integration of aperture diaphragm enables camera automatically choose aperture in P or S exposure modes, or to be dialed in on the camera body in A or M modes. EXIF data such as lens identification, focal length and aperture are supported. Autofocus is not supported.

Features

• Viewfinder display of aperture, zoom and distance. (Distance display requires lens which supports distance information.)
• Auto exposure.
• Assignable function button.
• Supports image stabilization (IS) lenses.
• Power is supplied by camera body. No external power source is required.
• Adapter firmware is user-upgradable through the built-in micro USB port.
• Extra-large, geared iris ring.
• Secure breech-lock for locking the EF/EF-S mount lens solidly.
• Flocking material is coated inside the opening to reduce internal reflection.
• Tested with Sony CineAlta F5 and F55 camera bodies.

Tested Lenses

• Canon EF 40/2.8 STM
• Canon EF 50/1.2 L USM
• Canon EF 50/1.8 II
• Canon EF 85/1.2 L II USM
• Canon EF 100/2.8 USM
• Canon EF 135/2L
• Canon EF 200/2.8 L II
• Canon EF 28-80/3.5-5.6 II
• Canon EF 35-80/4-5.6
• Canon EF 70-200/2.8L IS USM II
• Canon EF 70-200/4L USM
• Canon EF 70-200/4-5.6L IS USM
• Canon EF 70-300/4-5.6L IS USM
• Canon EF Extender 1.4x III, EF 70-200/4 L USM
• Canon EF-S 17-35/2.8 IS USM
• Canon EF-S 18-55/3.5-5.6 IS II
• Sigma 50/1.4 EX DC HSM
• Sigma 50/1.4 DG HSM
• Sigma 17-35/2.8-4 EX DG HSM
• Sigma 18-35/1.8 DC HSM ART
• Sigma 18-125/3.8-5.6 DC OS HSM
• Tamron SP 17-50/2.8
• Tamron SP 24-70/2.8
• Tamron SP 70-200/2.8
• Tokina AT-X PRO SD 11-16/2.8 (IF) DX
