Neutrik NC3FM-C-B

Neutrik NC3FM-C-B World's first 3 pole unisex XLR cable connector, black

More information

17 € with VAT 14.05 € without VAT
-+
Availability
Shipment day: 07. 11.
To be sent > 5 pcs
Bratislava > 5 pcs

Show all accessories

Product description

Product description

Neutrik NC3FM-C-B World's first 3 pole unisex XLR cable connector, black

Features & Benefits

  • World's first unisex XLR
  • 3 pole male and female cable connector in one housing
  • Easy selectable gender - converted by sliding housing back and forth
  • Substitute adapters, ideal as an emergency kit
  • With all benefits of the XLR XX series

Technical Specifications:

  • Capacitance: ≤ 4 pF
  • Contact resistance: ≤ 3 mΩ
  • Rated voltage 1min: 1.5 kVdc
  • Insulation resistance: > 2 GΩ
  • Rated current per 1 contact: 16 A
  • Rated voltage: 50 V
  • Cable diameter: 3.5 - 8.0 mm
  • Force required to connect connectors: ≤ 20 N
  • Force required to disconnect connectors: ≤ 20 N
  • Lifetime: > 1000 connection cycles
  • Conductor: max. 2.5 mm², max. 14 AWG
  • Wiring: Soldering
  • Cable cap: polyurethane
  • Contact plating: 0.2 µm Au
  • Contact material: Brass (CuZn39Pb3) (male)
  • Insert: Polyamide (PA 6.6 30% GR)
  • Lock: Zinc diecast (ZnAl4Cu1) / Ck 67 (spring)
  • Connector body: Zinc diecast (ZnAl4Cu1)
  • Shell: Black chromium
  • Shell plating: Nickel
  • Strain relief: Polyacetal (POM)
Parameters

Parameters

Manufacturer: Neutrik
Category: Audio connectors

Main parameters

TypeXLR
Number of poles3
ColourBlack

Other parameters

VersionOn the cable
VersionSoldering
VersionMale
VersionFemales
