The Sony FX6 provides cinematic expression to professional filmmakers andfreelancers of tomorrow. With a light and modular body, it recordsoutstanding 4K full frame quality at up to 120p with excellent low lightcapabilities and wide dynamic range. Part of the newly developed Cinemaline, It allows for more shooting expressions with the inclusion of SCINETONE…
The Sony FX6 provides cinematic expression to professional filmmakers andfreelancers of tomorrow. With a light and modular body, it recordsoutstanding 4K full frame quality at up to 120p with excellent low lightcapabilities and wide dynamic range. Part of the newly developed Cinemaline, It allows for more shooting expressions with the inclusion of SCINETONE picture profiles, fast and accurate Autofocus technology includingReal-time Eye Autofocus and a unique Variable ND filter to maintain acinematic look. The Sony Cinema line FX6 is designed for the future ofcinematic expressions.
Image Sensor
Image Sensor Size Full-FrameSensor Type CMOSSensor
Resolution Actual: 12.9 MP Effective: 10.2 MP
Color Filter Bayer
Shutter Type Rolling Shutter
ISO 800 (Native), 12,800 (Expanded), 320 to 409,600 (Expanded)
Gain -3 to 30 dB
Advertised Dynamic Range 15 Stops
CameraLens Mount Sony E-Mount
Lens Communication Yes
Interchangeable Lens Mount None
Shutter Speed 1/1 to 1/8000 sec
Built-In ND Filter 1/4 to 1/128 Stop Electronic ND Filter
Built-In Microphone Type Stereo, Mono
Media/Memory Card Slot Dual Slot: CFexpress Type A / SD
Variable Frame Rates DCI 4K: 1 to 60 fps, UHD: 1 Up to 120 fps, 1080p: 1 Up to 240 fps
Internal Recording
Recording Modes XAVC-I 4:2:2
10-Bit:4096 x 2160p at 23.98/24/25/29.97/50/59.94 fps (240 to 600 Mb/s) 3840 x 2160p at 23.98/25/29.97/50/59.94 fps (240 to 600 Mb/s) 1920 x 1980p at 23.98/25/29.97/50/59.94 fps (89 to 222 Mb/s) XAVC-L 4:2:0
8-Bit:3840 x 2160p at 23.98/25/29.97/50/59.94 fps (100 to 150 Mb/s) XAVC-L 4:2:2
10-Bit:1920 x 1080p at 23.98/25/29.97/50/59.94 fps (35 to 50 Mb/s) Gamma Curve HDR-HLG, S Cinetone, Sony S-Log, Sony S-Log 3Audio Recording AVC-Intra: 2/4-Channel 24-Bit 48 kHz LPCM AudioAVC-Long: 2/4-Channel 24-Bit 48 kHz LPCM Audio
Still Image Support Not Specified by Manufacturer
External Recording
Raw Output SDI/BNC
In Raw Mode:4096 x 2160
16-Bit at 23.98/24/25/29.97/50/59.94 fps 3840 x 2160
16-Bit at 23.98/25/29.97/50/59.94 fps
Interfaces
Video Connectors 1 x BNC (12G-SDI) Output, 1 x HDMI Output
Audio Connectors 2 x 3-Pin XLR Mic/Line Level Input, 1 x 1/8" / 3.5 mm Stereo Headphone OutputOther I/O 1 x BNC Timecode Input/Output, 1 x USB Type-C, 1 x USB Micro-B, 1 x 2.5 mm Control
Wireless Interfaces 2.4 GHz, 5 GHz Wi-Fi
Display
Display Type Included External Touchscreen LCD
Size 3.5"
Resolution 1280 x 720 (2,760,000 Dot)
EVF
EVF Optional, Not Included
Power
Battery Type Sony BP-U Series
Power Connectors 1 x Barrel (19.5 VDC)
Input
Power Consumption 18 W
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature -4 to 140°F / -20 to 60°C
General
Dimensions 6 x 4.6 x 4.5" / 153 x 116 x 114 mm (Without Protrusions)Weight 2 lb / 890 g
Manufacturer: | SONY |
Category: | Digital Cinema |
Camera Sensor size | Full Frame |
Resolution | 4K (DCI) |
Type of bayonet | E-mount |
Output | HDMI |
Output | 12G SDI |
Version | film |
Record format | RAW |
FPS | 4K 60fps |
FPS | HD 240fps |
FPS | UHD 120fps |
Media type | SD card |
Media type | CFexpress |
Battery type | BP-U |
Colour depth | 10 bit |
Other features | Timecode |
Other features | WiFi |
